Next Gen 4 Direction Electromagnetic Vibration Testing Table With Multi Axis Capabilities
| Place of Origin | China |
|---|---|
| Brand Name | Neide |
| Certification | CE |
| Model Number | ND-802 |
| Document | Neide catalogue.pdf |
| Minimum Order Quantity | 1 set |
| Price | Negotiable |
| Packaging Details | Wooden Box(standard export packaging) |
| Delivery Time | 7-22 work days |
| Payment Terms | L/C,D/A,D/P,T/T,Western Union,MoneyGram |
| Supply Ability | 100sets/month |
Contact me for free samples and coupons.
whatsapp:0086 18588475571
wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Maximum Test Load | 0-60 Kg | Vibration Direction | Up And Down + Left And Right |
|---|---|---|---|
| Table Size | 500*500 Mm | Amplitude | 0-5mm (random, Varying With Frequency) |
| Maximum Acceleration | 10g | Vibration Waveform | Sine Wave (half Wave / Full Wave) |
| Brand | Neide | Customized | Welcome |
| Factory | Yes | Customer | More Than 500+ |
| Material | SUS304 Or Customized | After-sales Service | Yes |
| Transportation | By Sea | Reply For Probme | Within 24 Hours |
| Highlight | Multi Axis Electromagnetic Vibration Testing Table,220 V Electromagnetic Vibration Table |
||
Product Description
Next Gen 4 Direction Electromagnetic Vibration Testing Table With Multi Axis Capabilities
Product Specifications
| Attribute | Value |
|---|---|
| Maximum test load | 0-60 kg |
| Vibration direction | up and down + left and right |
| Table size | 500×500 mm |
| Amplitude | 0-5mm (random, varying with frequency) |
| Maximum acceleration | 10g |
| Vibration waveform | sine wave (half wave / full wave) |
| Brand | Neide |
| Material | SUS304 or customized |
Product Overview
The Next Generation Electromagnetic Vibration Testing Table is a versatile testing solution designed for rigorous quality control and product development across multiple industries. Its multi-axis capabilities allow for comprehensive vibration testing in four directions, simulating real-world conditions to evaluate product durability and structural integrity.
Key Features
- Multi-directional vibration testing (up/down + left/right)
- Adjustable amplitude (0-5mm) with frequency variation
- Multiple table size options available
- Advanced frequency control (1-600Hz)
- Multiple testing modes including frequency modulation and programmable tests
- Customizable vibration waveforms
- Precision time control functionality
Industry Applications
This vibration testing table is essential for quality assurance in:
- Defense and aerospace component testing
- Telecommunications equipment validation
- Electronics durability testing
- Automotive parts evaluation
- Consumer electronics quality control
Technical Specifications
| Table size options | 500×500 mm | 750×750 mm | 1000×1000 mm | 1500×1500 mm |
| Sweep frequency | 1-600Hz (adjustable) |
| Test functions | Frequency modulation, fixed frequency, programmable, time control |
| Frequency doubling function | Low-high frequency, high-low frequency, or recyclable patterns |
| Logarithmic function | Down-up frequency, up-down frequency, or recyclable patterns |
| Power supply | 220 V, 50 Hz |
Customization Available: We welcome customized solutions to meet specific testing requirements. Our team provides comprehensive after-sales support with 24-hour response time for any technical inquiries.
